DM-6005 Five Channel Dimmer, 24V

The DM-6005 is a high-capacity five-channel dimmer designed specifically for use with RGBAW five-color LED tape, but is compatible with any five-channel application. It’s built into a durable, powder-coated aluminum chassis with integrated cooling vents and four mounting holes for secure installation. Powered by a 600-watt Mean Well HLG600 power supply, the unit connects to standard 120V via a 5-15 Edison input receptacle (14-gauge extension cord recommended). Output is delivered through a six-pin Phoenix connector rated at 32 amps per pin. For remote control capability, a two-pin Phoenix connector is provided—simply remove the jumper and install an optional remote ON/OFF switch.  Specifications: 16 gauge aluminum chassis 600-watt output available in 24V DC IP65 rating, fully enclosed 10A x 5 per channel dimmer rating 32 Amp Phoenix chassis mount output connector Two-pin remote On/Off connector 5-15 Edison input receptacle Power coated 16ga steel chassis Size: 14” x 12” x 3” Weight: 12 lbs.
